Copper Tube Terminal 70mm Cable X M10 Hole - SWA - For Battery Cable - 70-10TQ

Tin plated copper tube terminal - 70-10TQ
70mm Cable X M10 Hole

Application: Un-insulated heavy duty terminals suitable for power cables up to 1000 volts .
Material: Manufactured from seamless copper tube to BS EN 12449:1999
Finish: Electro Tin plated to BS 1872:1974
Manufactured from 99.5% copper and fully annealed to ensure optimum ductility to avoid severe deformation such as cracking and splitting when crimped
Supplied with an inspection window which enables the user to ensure full and correct insertion of the conductor and a flared entry ensures a smooth transition from terminal to conductor
Internal barrel diameters suit standard cables as defined in BS 6360
All SWA terminals are identified on the palm with cable size (and stud hole size) to ensure correct selection of the appropriate tool and dies.
